Description
Product Detail :
| Ascend speed | 9- 10 m/min |
| Whole Machine Weight | 1928 Kg (Steel) 1814 Kg (Aluminum) |
| Suspension mechanism from front beam extent | 1.1 m 1.7m (Should reduce the load on suspended platform when extent is 1.5 m or more) |
| Suspension mechanism Weight | 2 x 175 Kg |
| Suspension mechanism Height adjustment | 1.15 m 1.75m |
| Suspended platform weight | 538 Kg (Steel) 424 Kg (Aluminum) |
| Suspended Platform size L x W x H | (2500x 3) x 760 x 1450mm |
| Safety Lock Type | Tilt Proof Safety Lock |
| Rated Load | 800Kgs |
| Minimum Breaking force | 65.5 kN |
| Hoist Related Lifting Force | 8 kN |
| Hoist Model | LTD 80 |
| Electric Motor Voltage | AC 380V, 3-Phases (AC415V, 3-Phases ) |
| Electric Motor Type | YEJ100L1-4 |
| Electric Motor Power | 2.2 kW |
| Electric Motor Braking Torque | 15N x m |
| Balance Weight | 1000 Kg |
